    018-8003 Moisture Barrier Bag ESD 203x508mm 152.4um (Pack 100units)

    018-8003 Moisture Barrier Bag ESD 203x508mm 152.4um (Pack 100units)

    https://www.icompplus.com/web/image/product.template/93985/image_1920?unique=58653b0

    018-8003

    Antistatic Bags

    90.00 € 90.0 EUR 90.00 €

    90.00 €

    Not Available For Sale

    • Brand
    • COO
    • RoHS
    • Type of Bag
    • Surface resistance
    • Thickness
    • Type of material
    • Download time
    • Quantity per package
    • Static Shielding
    • MVTR
    • Width
    • Accessory Type
    • Length
    • Closure Type
    • Traceability
    • Packaging
    • Reach

    This combination does not exist.

    RoHS :
    Datasheet :
    : Moisture Barrier Bag ESD 203x508mm 152.4um (Pack 100units)
    IN STOCK:
    THE DELIVERY WILL OCCUR WITHIN 24/48 HOURS AFTER THE STOCK ARRIVES AT OUR WAREHOUSE. View Options
    (Request a quote for large quantities or custom projects)

    TECHNICAL FEATURES

    Brand ANTISTAT
    COO CHINA
    Type of Bag Moisture Barrier Bags
    Surface resistance 10e4-<10e11Ω
    Thickness 152.4µm
    Type of material 4-layer metallized plastic
    Download time ≤ 2sec iEc61340-5-1 (±1000 - ±100V)
    Quantity per package 100units
    Static Shielding <10nJ
    MVTR ≤ 0,0003 g/100 pulg2/24h
    Width 203mm
    Accessory Type ESD Protective Bag
    Length 508mm
    Closure Type Thermal
    Packaging Bag
    Reach Yes

    PRODUCT DESCRIPTION

    Moisture Barrier Bag ESD 203x508mm 152.4um (Pack 100units)

    Nuestras bolsas de barrera contra la humedad resistentes a perforaciones de 6 mil protegen los productos sensibles tanto de daños por descargas electrostáticas (ESD) como de daños por humedad durante el envío y el almacenamiento. Adecuadas para sellar al vacío, estas bolsas ofrecen la máxima resistencia al vapor y al oxígeno. Además, el material opaco y hermético a la luz garantiza que el contenido no pueda verse desde el exterior, ofreciendo una seguridad adicional.


    PHYSICAL TYPICAL VALUE TESTING METHOD
    Water vapour transmission rate (WVTR) < 0.0003 grams/100 sq. in./24 hrs ASTM F1249
    Tensile strength 7500 PSI MD and TD ASTM D882-18
    Puncture resistance 34 lbs MIL-STD-3010 Method 2065
    Seal strength 22 lbs ASTM D882-18
    Thickness 6 MIL .1524mm +/-10% MIL-STD-3010 Method 1003
    ELECTRICAL TYPICAL VALUE TESTING METHOD
    Discharge shielding <10 nJ ANSI/ESD STM11.31-2018
    Surface resistance - Interior 1 x 10⁴ to < 1 x 10¹¹ Ω ANSI/ESD STM11.11-2022
    Surface resistance - Exterior x 10⁴ to < 1 x 10¹¹ Ω ANSI/ESD STM11.11-2022
    Surface resistivity - Interior > 1x10⁵ Ω/sq ≤ 1x1012 Ω/sq ASTM D257-14
    Surface resistivity - Exterior ≤ 1x10¹² Ω/sq ASTM D257-14
    HEAT SEALING CONDITIONS TYPICAL VALUE TESTING METHOD
    Temperature range 356ºF - 3920ºF __
    Sealing pressure 40 - 60 PS __
    Sealing time 2.0 - 3.8 S __
    CORROSION TYPICAL VALUE TESTING METHOD
    Contact corrosion No evidence of corrosion or pitting FTMS 101C METHOD 3005
    Non-corrosive Pass MIL-STD-3010 METHOD 3005
    SHELF LIFE TYPICAL VALUE TESTING METHOD
    3 Years from date of manufacture When kept in storage conditions
    of ≤ 30oc/60% RH    		 __


    PRODUCT DOCUMENTATION

    Datasheet
