    DVL 1500-UI Sensor DVL Voltage 1500V

    DVL 1500-UI Sensor DVL Voltage 1500V

    https://icompplus.odoo.com/web/image/product.template/97478/image_1920?unique=1a9cf9f

    DVL 1500-UI

    Sensores de Voltaje

    318.20 € 318.2 EUR 318.20 €

    318.20 €

    Not Available For Sale

    • Brand
    • COO
    • RoHS
    • Type of primary signal
    • Mounting
    • Operating Temperature
    • Nominal signal type
    • Supply voltage type
    • Primary current measuring range
    • Sensor type
    • Serie
    • Precision
    • Nominal Value
    • Supply Voltage Range
    • Secondary Nominal Signal Value
    • Measurement
    • Technology
    • Traceability
    • Packaging
    • Standard Package
    • Reach

    This combination does not exist.

    RoHS :
    Datasheet :
    : Sensor DVL Voltage 1500V
    IN STOCK:
    THE DELIVERY WILL OCCUR WITHIN 24/48 HOURS AFTER THE STOCK ARRIVES AT OUR WAREHOUSE. View Options
    (Request a quote for large quantities or custom projects)

    TECHNICAL FEATURES

    Brand LEM
    COO GERMANY
    Type of primary signal AC + DC
    Mounting Panel
    Operating Temperature -40°C ~ 85°C
    Nominal signal type Current
    Supply voltage type DC External Bipolar
    Primary current measuring range 1500V
    Sensor type Voltage Transducer
    Serie DVL
    Precision 0.5%
    Nominal Value 1500V
    Supply Voltage Range 15-24V
    Secondary Nominal Signal Value Instantaneous unidirectional 4-20mA
    Measurement Voltage
    Technology Insulation Digital Technology
    Packaging Box
    Standard Package 12
    Reach Yes

    PRODUCT DESCRIPTION

    Sensor Voltaje DVL 1500V

    Mainly intended for electronic voltage measurement: DC, AC, pulsed..., within different sectors such as Railway or Industrial. It has galvanic separation between the primary and secondary circuits.

    Features
    Unipolar and insulated measurement of positive voltage up to 1500V
    4-20 mA output
    Input and output connections with M5 studs
    Compatible with AV 100 family

    Advantages
    Low consumption and low losses
    Compact design
    Good behavior under common mode variations
    Excellent accuracy (offset, sensitivity, linearity)
    Good delay time
    Low temperature variation
    High immunity to external interferences

    Applications
    Substations
    Trackside
    Railway (fixed installations and onboard)
    Industrial

    Standards
    EN 50155: 2021
    EN 50178: 1997
    EN 50124-1: 2017
    EN 50121-3-2: 2016
    UL 508: 2013

    PRODUCT DOCUMENTATION

    Datasheet
