    LV 100-2000/SP5 Voltaje Sensor DVL 2000V

    LV 100-2000/SP5 Voltaje Sensor DVL 2000V

    https://icompplus.odoo.com/web/image/product.template/99635/image_1920?unique=4787fa9

    LV 100-2000/SP5

    Sensores de Voltaje

    335.70 € 335.7 EUR 335.70 €

    335.70 €

    Not Available For Sale

    • Brand
    • COO
    • RoHS
    • Type of primary signal
    • Mounting
    • Operating Temperature
    • Nominal signal type
    • Supply voltage type
    • Primary current measuring range
    • Sensor type
    • Serie
    • Precision
    • Nominal Value
    • Supply Voltage Range
    • Secondary Nominal Signal Value
    • Measurement
    • Traceability
    • Packaging
    • Standard Package

    This combination does not exist.

    RoHS :
    Datasheet :
    : Voltaje Sensor DVL 2000V
    IN STOCK:
    THE DELIVERY WILL OCCUR WITHIN 24/48 HOURS AFTER THE STOCK ARRIVES AT OUR WAREHOUSE. View Options
    (Request a quote for large quantities or custom projects)

    TECHNICAL FEATURES

    Brand LEM
    COO GERMANY
    Type of primary signal AC + DC
    Mounting Panel
    Operating Temperature -25°C ~ 70°C
    Nominal signal type Voltage
    Supply voltage type DC External Bipolar
    Primary current measuring range 3000V
    Sensor type Voltage Transducer
    Serie LV 100-VOLTAGE
    Precision 0.9%
    Nominal Value 2000V
    Supply Voltage Range 15-24V
    Secondary Nominal Signal Value Instantaneous 50mA
    Measurement Voltage
    Packaging Box
    Standard Package 4

    PRODUCT DESCRIPTION

    Voltaje Sensor DVL 2000V

    For the electronic measurement of voltages: DC, AC, pulsed..., with galvanic separation between the primary circuit and the secondary circuit.

    Features
    Closed loop (compensated) voltage transducer using the Hall effect
    Insulating plastic case recognized according to UL 94-V0
    Primary resistor . incorporatedwithin the housing.

    Special features
    UC = ±115 ... 24 (±15 %) V
    Ud = 9 kV
     TA = -25 °C … +70 °C

    Advantages
    Excellent accuracy
    Very good linearity
    Low temperature drift
    Optimized delay time
    Wide frequency bandwith
    High immunity to external interference

    Applications
    Single or three phase inverters
    Propulsion and braking choppers
    Propulsion converters
    Auxiliary converters
    Battery chargers.
    Application domain
    Railway (fixed installations andonboard)
