MOBILE
|
|
|
Mobile module |
4G
(LTE) – Cat 4 up to 150 Mbps, 3G – Up to 42 Mbps, 2G – Up to 236.8 kbps |
|
3GPP Release |
Release
9 |
|
Status |
IMSI,
ICCID, operator, operator state, data connection state, network type,
bandwidth, connected band, signal strength (RSSI), SINR, RSRP, RSRQ, EC/IO,
RSCP, data sent/received, LAC, TAC, cell ID, ARFCN, UARFCN, EARFCN, MCC,
and MNC |
|
SMS |
SMS
status, SMS configuration, send/read SMS via HTTP POST/GET, EMAIL to SMS, SMS
to EMAIL, SMS to HTTP, SMS to SMS, scheduled SMS, SMS autoreply, SMPP |
|
USSD |
Supports
sending and reading Unstructured Supplementary Service Data messages |
|
Black/White list |
Operator
black/white list (by country or separate operators) |
|
Multiple PDN |
Possibility
to use different PDNs for multiple network access and services |
|
Band management |
Band
lock, Used band status display |
|
APN |
Auto
APN |
|
Bridge |
Direct
connection (bridge) between mobile ISP and device on LAN |
|
Passthrough |
Router
assigns its mobile WAN IP address to another device on LAN |
WIRELESS
|
|
|
Wireless mode |
IEEE
802.11b/g/n, Access Point (AP), Station (STA) |
|
Wi-Fi security |
WPA2-Enterprise
- PEAP, WPA2-PSK, WPA-EAP, WPA-PSK, WPA3-SAE, WPA3-EAP, OWE; AES-CCMP, TKIP,
Auto-cipher modes, client separation, EAP-TLS with PKCS#12 certificates,
disable auto-reconnect |
|
SSID/ESSID |
SSID
stealth mode and access control based on MAC address |
|
Wi-Fi users |
Up
to 50 simultaneous connections |
|
Wireless Connectivity
Features |
Fast
roaming (802.11r), Relayd, BSS transition management (802.11v), radio
resource measurement (802.11k) |
|
Wireless MAC filter |
Whitelist,
blacklist |
|
Wireless QR code generator |
Once
scanned, a user will automatically enter your network without needing to
input login information. |
NETWORK
|
|
|
Hotspot |
Captive
portal (hotspot), internal/external Radius server, Radius MAC authentication,
SMS authorisation, internal/external landing page, walled garden, user
scripts, URL parameters, user groups, individual user or group limitations,
user management, 9 default customisable themes and optionality to upload and
download customised hotspot themes |
|
Routing |
Static
routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), Policy based
routing |
|
Network protocols |
TCP,
UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP,
VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan
(WOL) |
|
VoIP passthrough support |
H.323
and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets |
|
Connection monitoring |
Ping
Reboot, Wget Reboot, Periodic Reboot, LCP and ICMP for link inspection |
|
Firewall |
Port
forward, traffic rules, custom rules |
|
Firewall status page |
View
all your Firewall statistics, rules, and rule counters |
|
Ports management |
View
device ports, enable and disable each of them, turn auto-configuration on or
off, change their transmission speed, and so on |
|
Network topology |
Visual
representation of your network, showing which devices are connected to which
other devices |
|
DHCP |
Static
and dynamic IP allocation, DHCP relay, DHCP server configuration, status,
static leases: MAC with wildcards |
|
QoS / Smart Queue Management
(SQM) |
Traffic
priority queuing by source/destination, service, protocol or port, WMM,
802.11e |
|
DDNS |
Supported
>25 service providers, others can be configured manually |
|
Network backup |
Wi-Fi
WAN, Mobile, VRRP, Wired options, each of which can be used as an automatic
Failover |
|
Load balancing |
Balance
Internet traffic over multiple WAN connections |
|
SSHFS |
Possibility
to mount remote file system via SSH protocol |
ETHERNET
|
|
|
WAN |
1
x WAN port 10/100 Mbps, compliance IEEE 802.3, IEEE 802.3u, 802.3az
standards, supports auto MDI/MDIX |
|
LAN |
1
x LAN port, 10/100 Mbps, compliance with IEEE 802.3, IEEE 802.3u standards,
supports auto MDI/MDIX |
|
SECURITY
|
|
|
Authentication |
Pre-shared
key, digital certificates, X.509 certificates, TACACS+, Radius, IP &
login attempts block, time-based login blocking, built-in random password
generator |
|
Firewall |
Pre-configured
firewall rules can be enabled via WebUI, unlimited firewall configuration via
CLI; DMZ; NAT; NAT-T |
|
Attack prevention |
DDOS
prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack
prevention), port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN
scan attacks) |
|
VLAN |
Port
and tag-based VLAN separation |
|
Mobile quota control |
Mobile
data limit, customizable period, start time, warning limit, phone number |
|
WEB filter |
Blacklist
for blocking out unwanted websites, Whitelist for specifying allowed sites
only |
|
Access control |
Flexible
access control of SSH, Web interface, CLI and Telnet |
VPN
|
|
|
OpenVPN |
Multiple
clients and a server can run simultaneously, 27 encryption methods |
|
OpenVPN Encryption |
DES-CBC
64, RC2-CBC 128, DES-EDE-CBC 128, DES-EDE3-CBC 192, DESX-CBC 192, |
| OpenVPN Encryption |
BF-CBC 128, RC2-40-CBC 40, CAST5-CBC 128, RC2-64-CBC 64, AES-128-CBC 128,
AES-128-CFB 128, AES-128-CFB1 128, AES-128-CFB8 128, AES-128-OFB 128,
AES-128-GCM 128, AES-192-CFB 192, AES-192-CFB1 192, AES-192-CFB8 192,
AES-192-OFB 192, AES-192-CBC 192, AES-192-GCM 192, AES-256-GCM 256,
AES-256-CFB 256, AES-256-CFB1 256, AES-256-CFB8 256, AES-256-OFB 256,
AES-256-CBC 256 |
|
IPsec |
IKEv1,
IKEv2, with 14 encryption methods for IPsec (3DES, DES, AES128, AES192,
AES256, AES128GCM8, AES192GCM8, AES256GCM8, AES128GCM12, AES192GCM12,
AES256GCM12, AES128GCM16, AES192GCM16, AES256GCM16) |
|
GRE |
GRE
tunnel, GRE tunnel over IPsec support |
|
PPTP, L2TP |
Client/Server
instances can run simultaneously, L2TPv3, L2TP over IPsec support |
|
Stunnel |
Proxy
designed to add TLS encryption functionality to existing clients and servers
without any changes in the program’s code |
|
DMVPN |
Method
of building scalable IPsec VPNs |
|
SSTP |
SSTP
client instance support |
|
ZeroTier |
ZeroTier
VPN client support |
|
WireGuard |
WireGuard
VPN client and server support |
|
Tinc |
Tinc
offers encryption, authentication and compression in it's tunnels. Client and
server support. |
OPC UA
|
|
|
Supported modes |
Client,
Server |
|
Supported connection types |
TCP |
|
MODBUS
|
|
|
Supported modes |
Server,
Client |
|
Supported connection types |
TCP |
|
Custom registers |
MODBUS
TCP custom register block requests, which read/write to a file inside the
router, and can be used to extend MODBUS TCP Client functionality |
|
Supported data formats |
8-bit:
INT, UINT; 16-bit: INT, UINT (MSB or LSB first); 32-bit: float, INT, UINT
(ABCD (big-endian), DCBA (little-endian), CDAB, BADC), HEX, ASCII |
DATA TO SERVER
|
|
|
Protocol |
HTTP(S),
MQTT, Azure MQTT, Kinesis |
|
Data to server |
Extract
parameters from multiple sources and different protocols, and send them all
to a single server |
MQTT GATEWAY
|
|
|
Modbus MQTT Gateway |
Allows
sending commands and receiving data from MODBUS Server through MQTT broker |
DNP3
|
|
|
Supported modes |
Station,
Outstation |
|
Supported connection |
TCP |
|
DLMS
|
|
|
DLMS Support |
DLMS
- standard protocol for utility meter data exchange |
|
Supported modes |
Client |
|
Supported connection types |
|
API
|
|
|
Teltonika Networks Web API
(beta) support |
Expand
your device's possibilities by using a set of configurable API endpoints to
retrieve or change data. For more information, please refer to this
documentation: https://developers.teltonika-networks.com |
MONITORING & MANAGEMENT
|
|
|
WEB UI |
HTTP/HTTPS,
status, configuration, FW update, CLI, troubleshoot, multiple event log
servers, firmware update availability notifications, event log, system log,
kernel log, Internet status |
|
FOTA |
Firmware
update from server, automatic notification |
|
SSH |
SSH
(v1, v2) |
|
SMS |
SMS
status, SMS configuration, send/read SMS via HTTP POST/GET |
|
Call |
Reboot,
Status, Mobile data on/off, Output on/off, answer/hang-up with a timer, Wi-Fi
on/off |
|
TR-069 |
OpenACS,
EasyCwmp, ACSLite, tGem, LibreACS, GenieACS, FreeACS, LibCWMP, Friendly tech,
AVSystem |
|
MQTT |
MQTT
Broker, MQTT publisher |
|
SNMP |
SNMP
(v1, v2, v3), SNMP Trap |
|
JSON-RPC |
Management
API over HTTP/HTTPS |
|
RMS |
Teltonika
Remote Management System (RMS) |
IOT PLATFORMS
|
|
|
Cloud of Things |
Allows
monitoring of: Device data, Mobile data, Network info, Availability |
|
ThingWorx |
Allows
monitoring of: WAN Type, WAN IP, Mobile Operator Name, Mobile Signal
Strength, Mobile Network Type |
|
Cumulocity |
Allows
monitoring of: Device Model, Revision and Serial Number, WAN Type and IP,
Mobile Cell ID, ICCID, IMEI, Connection Type, Operator, Signal Strength |
|
Azure IoT Hub |
Can
send device IP, Number of bytes send/received, Temperature, PIN count to
Azure IoT Hub server, Mobile connection state, Network link state,
IMEI, ICCID, Model, Manufacturer, Serial, Revision, IMSI, SIM State, PIN
state, GSM signal, WCDMA RSCP, WCDMA EC/IO, LTE RSRP, LTE SINR, LTE RSRQ,
CELL ID, Operator, Operator number, Connection type |
SYSTEM CHARACTERISTICS
|
|
|
CPU |
Mediatek,
580 MHz, MIPS 24KEc |
|
RAM |
128
MB, DDR2 |
|
FLASH storage |
16
MB, SPI Flash |
FIRMWARE / CONFIGURATION
|
|
|
WEB UI |
Update
FW from file, check FW on server, configuration profiles, configuration
backup |
|
FOTA |
Update
FW |
|
RMS |
Update
FW/configuration for multiple devices at once |
|
Keep settings |
Update
FW without losing current configuration |
|
Factory settings reset |
A
full factory reset restores all system settings, including the IP address,
PIN, and user data to the default manufacturer's configuration |
FIRMWARE CUSTOMISATION
|
|
|
Operating system |
RutOS
(OpenWrt based Linux OS) |
|
Supported languages |
Busybox
shell, Lua, C, C++ |
|
Development tools |
SDK
package with build environment provided |
|
GPL customization |
You
can create your own custom, branded firmware and web page application by
changing colours, logos, and other elements in our firmware to fit your or
your clients’ needs. |
INPUT / OUTPUT
|
|
|
Input |
1
x Digital Input, 0 - 6 V detected as logic low, 8 - 30 V detected as logic
high |
|
Output |
1
x Digital Output, Open collector output, max output 30 V, 300 mA |
|
Events |
Email,
RMS, SMS |
|
I/O juggler |
Allows
to set certain I/O conditions to initiate event |
POWER
|
|
|
Connector |
4-pin
industrial DC power socket |
|
Input voltage range |
9
– 30 VDC, reverse polarity protection; surge protection >31 VDC 10us max |
|
PoE (passive) |
Passive
PoE over spare pairs. Possibility to power up through LAN1 port, not
compatible with IEEE802.3af, 802.3at and 802.3bt standards, Mode B, 9 - 30
VDC |
|
Power consumption |
<
6.5 W Max |
PHYSICAL INTERFACES
|
|
|
Ethernet |
2
x RJ45 ports, 10/100 Mbps |
|
I/O’s |
1
x Digital Input, 1 x Digital Output on 4-pin power connector |
|
Status LEDs |
3
x Connection type status LEDs, 5 x Connection strength LEDs, 2 x LAN status
LEDs, 1 x Power LED |
|
SIM |
1
x SIM slot (Mini SIM – 2FF), 1.8 V/3 V, external SIM holder |
|
Power |
1
x 4-pin power connector |
|
Antennas |
2
x SMA for LTE, 1 x RP-SMA for Wi-Fi antenna connectors |
|
Reset |
Reboot/User
default reset/Factory reset button |
PHYSICAL SPECIFICATION
|
|
|
Casing material |
Aluminium
housing, plastic panels |
|
Dimensions (W x H x D) |
83
x 25 x 74 mm |
|
Weight |
125
g |
|
Mounting options |
DIN
rail, wall mount, flat surface (all require additional kit) |
OPERATING ENVIRONMENT
|
|
|
Operating temperature |
-40
°C to 75 °C |
|
Operating humidity |
10%
to 90% non-condensing |
|
Ingress Protection Rating |
IP30 |
|
REGULATORY & TYPE APPROVALS
|
|
|
Regulatory |
CE,
UKCA, RCM, EAC, Anatel, ANRT, Kenya, ICASA, NCC, ETA-WPC, SIRIM, IMDA, NTC,
NBTC, MTC NOM, E-mark, CB, RoHS, REACH, R118 |
EMC EMISSIONS & IMMUNITY
|
|
|
Standards |
EN
55032:2015 + A1:2020 |
| Standards |
EN 55035:2017 + A11:2020 |
| Standards |
EN IEC 61000-3-2:2019 |
| Standards |
EN 61000-3-3:2013 + A1:2019 |
| Standards |
EN 301 489-1 V2.2.3 |
| Standards |
EN 301 489-17 V3.2.4 |
| Standards |
EN 301 489-52 V1.2.1 |
|
ESD |
EN
61000-4-2:2009 |
|
Radiated Immunity |
EN
IEC 61000-4-3:2020 |
|
EFT |
EN
61000-4-4:2012 |
|
Surge Immunity (AC Mains
Power Port) |
EN
61000-4-5:2014 + A1:2017 |
|
CS |
EN
61000-4-6:2014 |
|
DIP |
EN
61000-4-11:2020 |
RF
|
|
|
Standards |
EN
300 328 V2.2.2 |
| Standards |
EN 301 511 V12.5.1 |
| Standards |
EN 301 908-1 V15.1.1 |
| Standards |
EN 301 908-2 V13.1.1 |
| Standards |
EN 301 908-13 V13.1.1 |
SAFETY
|
|
|
Standards |
CE:
EN IEC 62368-1:2020 + A11:2020, EN IEC 62311:2020, EN 50665:2017 |
| Standards |
RCM: AS/NZS 62368.1:2022 |
| Standards |
CB: IEC 62368-1:2018
|
