MOBILE
|
|
|
Mobile module |
2
x 4G (LTE) – Cat 6 up to 300 Mbps, 3G – up to 42 Mbps |
|
Status |
Signal
strength (RSSI), SINR, RSRP, RSRQ, EC/IO, RSCP, Bytes sent/received,
connected band, IMSI, ICCID, Carrier aggregation |
|
SMS |
SMS
status, SMS configuration, send/read SMS via HTTP POST/GET, EMAIL to SMS, SMS
to EMAIL, SMS to HTTP, SMS to SMS, scheduled SMS, SMS autoreply, SMPP |
|
USSD |
Supports
sending and reading Unstructured Supplementary Service Data messages |
|
Black/White
list |
Operator
black/white list |
|
Multiple PDN |
Possibility
to use different PDNs for multiple network access and services |
|
Band
management |
Band
lock, Used band status display |
|
SIM idle
protection service |
When
working with devices with two SIM slots, the one not currently in use will
remain idle until the device switches to it, meaning that no data is used on
the card until then |
|
APN |
Auto
APN |
|
Bridge |
Direct
connection (bridge) between mobile ISP and device on LAN |
|
Passthrough |
Router
assigns its mobile WAN IP address to another device on LAN |
WIRELESS
|
|
|
Wireless mode |
802.11b/g/n/ac
Wave 2 (WiFi 5) with data transmission rates up to 867 Mbps (Dual Band,
MU-MIMO), 802.11r fast transition, Access Point (AP), Station (STA) |
|
Wi-Fi
security |
WPA2-Enterprise
- PEAP, WPA2-PSK, WEP, WPA-EAP, WPA-PSK; AES-CCMP, TKIP, Auto Cipher modes,
client separation |
|
SSID/ESSID |
ESSID
stealth mode |
|
Wi-Fi users |
up
to 150 simultaneous connections |
|
Wireless
Connectivity Features |
Wireless
mesh (802.11s), fast roaming (802.11r), Relayd |
|
Wireless MAC
filter |
Whitelist,
blacklist |
|
Wireless QR
code generator |
Once
scanned, a user will automatically enter your network without needing to
input login information. |
NETWORK
|
|
|
Hotspot |
Captive
portal (Hotspot), internal/external Radius server, SMS authorization,
internal/external landing page, walled garden, user scripts, URL parameters,
user groups, individual user or group limitations, user management, 9 default
customizable themes and option to upload and download customised hotspot
themes |
|
Routing |
Static
routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), Policy based
routing |
|
Network
protocols |
TCP,
UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP,
VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan
(WOL) |
|
VoIP
passthrough support |
H.323
and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packets |
|
Connection
monitoring |
Ping
Reboot, Wget Reboot, Periodic Reboot, LCP and ICMP for link inspection |
|
Firewall |
Port
forward, traffic rules, custom rules |
|
Firewall
status page |
View
all your Firewall statistics, rules, and rule counters |
|
Ports
management |
View
device ports, enable and disable each of them, turn auto-configuration on or
off, change their transmission speed, and so on |
|
Network
topology |
Visual
representation of your network, showing which devices are connected to which
other devices |
|
Hotspot |
Captive
portal (Hotspot), internal/external Radius server, SMS authorization,
internal/external landing page, walled garden, user scripts, URL parameters,
user groups, individual user or group limitations, user management, 9 default
customizable themes and option to upload and download customised hotspot
themes |
|
DHCP |
Static
and dynamic IP allocation, DHCP Relay |
|
QoS / Smart
Queue Management (SQM) |
Traffic
priority queuing by source/destination, service, protocol or port, WMM,
802.11e |
|
DDNS |
Supported
>25 service providers, others can be configured manually |
|
Network
backup |
Wi-Fi
WAN, Mobile, VRRP, Wired options, each of which can be used as an automatic
Failover |
|
Load
balancing |
Balance
Internet traffic over multiple WAN connections |
|
SSHFS |
Possibility
to mount remote file system via SSH protocol |
BLUETOOTH
|
|
|
Bluetooth 4.0 |
Bluetooth
low energy (LE) for short range communication |
ETHERNET
|
|
|
WAN |
1
x WAN port 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az
standards, supports auto MDI/MDIX crossover |
|
LAN |
4
x LAN ports, 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u,
802.3az standards, supports auto MDI/MDIX crossover |
|
SECURITY
|
|
|
Authentication |
Pre-shared
key, digital certificates, X.509 certificates, TACACS+, Radius, IP &
Login attempts block |
|
Firewall |
Pre-configured
firewall rules can be enabled via WebUI, unlimited firewall configuration via
CLI; DMZ; NAT; NAT-T |
|
Attack
prevention |
DDOS
prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack
prevention), port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN
scan attacks) |
|
VLAN |
Port
and tag-based VLAN separation |
|
Mobile quota
control |
Mobile
data limit, customizable period, start time, warning limit, phone number |
|
WEB filter |
Blacklist
for blocking out unwanted websites, Whitelist for specifying allowed sites
only |
|
Access
control |
Flexible
access control of SSH, Web interface, CLI and Telnet |
VPN
|
|
|
OpenVPN |
Multiple
clients and a server can run simultaneously, 27 encryption methods |
|
OpenVPN
Encryption |
DES-CBC
64, RC2-CBC 128, DES-EDE-CBC 128, DES-EDE3-CBC 192, DESX-CBC 192, |
|
OpenVPN
Encryption |
BF-CBC 128, RC2-40-CBC 40, CAST5-CBC 128, RC2-64-CBC 64,
AES-128-CBC 128, AES-128-CFB 128, AES-128-CFB1 128, AES-128-CFB8 128,
AES-128-OFB 128, AES-128-GCM 128, AES-192-CFB 192, AES-192-CFB1 192,
AES-192-CFB8 192, AES-192-OFB 192, AES-192-CBC 192, AES-192-GCM 192,
AES-256-GCM 256, AES-256-CFB 256, AES-256-CFB1 256, AES-256-CFB8 256,
AES-256-OFB 256, AES-256-CBC 256 |
|
IPsec |
IKEv1,
IKEv2, with 14 encryption methods for IPsec (3DES, DES, AES128, AES192,
AES256, AES128GCM8, AES192GCM8, AES256GCM8, AES128GCM12, AES192GCM12,
AES256GCM12, AES128GCM16, AES192GCM16, AES256GCM16) |
|
GRE |
GRE
tunnel, GRE tunnel over IPsec support |
|
PPTP, L2TP |
Client/Server
instances can run simultaneously, L2TPv3, L2TP over IPsec support |
|
Stunnel |
Proxy
designed to add TLS encryption functionality to existing clients and servers
without any changes in the program’s code |
|
DMVPN |
Method
of building scalable IPsec VPNs |
|
SSTP |
SSTP
client instance support |
|
ZeroTier |
ZeroTier
VPN client support |
|
WireGuard |
WireGuard
VPN client and server support |
|
Tinc |
Tinc
offers encryption, authentication and compression in it's tunnels. Client and
server support. |
OPC UA
|
|
|
Supported
modes |
Client,
Server (planned) |
|
Supported
connection types |
TCP |
MODBUS TCP SLAVE
|
|
|
ID range |
Respond
to one ID in range [1;255] or any |
|
Allow Remote
Access |
Allow
access through WAN |
|
Custom
registers |
MODBUS
TCP custom register block requests, which read/write to a file inside the
router, and can be used to extend MODBUS TCP Slave functionality |
MODBUS TCP MASTER
|
|
|
Supported
functions |
01,
02, 03, 04, 05, 06, 15, 16 |
|
Supported
data formats |
8-bit:
INT, UINT; 16-bit: INT, UINT (MSB or LSB first); 32-bit: float, INT, UINT
(ABCD (big-endian), DCBA (little-endian), CDAB, BADC) |
|
DATA TO SERVER
|
|
|
Protocol |
HTTP(S),
MQTT, Azure MQTT, Kinesis |
|
Data to
server |
Extract
parameters from multiple sources and different protocols, and send them all
to a single server |
MQTT GATEWAY
|
|
|
MQTT Gateway |
Allows
sending commands and receiving data from MODBUS Master through MQTT broker |
DNP3
|
|
|
Supported
modes |
TCP
Master, DNP3 Outstation |
DLMS
|
|
|
DLMS Support |
DLMS
- standard protocol for utility meter data exchange |
|
MONITORING & MANAGEMENT
|
|
|
WEB UI |
HTTP/HTTPS,
status, configuration, FW update, CLI, troubleshoot, event log, system log,
kernel log |
|
FOTA |
Firmware
update from server, automatic notification |
|
SSH |
SSH
(v1, v2) |
|
SMS |
SMS
status, SMS configuration, send/read SMS via HTTP POST/GET |
|
Call |
Reboot,
Status, Mobile data on/off, Output on/off, answer/hang-up with a timer, Wi-Fi
on/off |
|
TR-069 |
OpenACS,
EasyCwmp, ACSLite, tGem, LibreACS, GenieACS, FreeACS, LibCWMP, Friendly tech,
AVSystem |
|
MQTT |
MQTT
Broker, MQTT publisher |
|
SNMP |
SNMP
(v1, v2, v3), SNMP Trap |
|
JSON-RPC |
Management
API over HTTP/HTTPS |
|
RMS |
Teltonika
Remote Management System (RMS) |
IOT PLATFORMS
|
|
|
Cloud of
Things |
Allows
monitoring of: Device data, Mobile data, Network info, Availability |
|
ThingWorx |
Allows
monitoring of: WAN Type, WAN IP, Mobile Operator Name, Mobile Signal
Strength, Mobile Network Type |
|
Cumulocity |
Allows
monitoring of: Device Model, Revision and Serial Number, WAN Type and IP,
Mobile Cell ID, ICCID, IMEI, Connection Type, Operator, Signal Strength |
|
Azure IoT Hub |
Can
send device IP, Number of bytes send/received, Temperature, PIN count to
Azure IoT Hub server, Mobile connection state, Network link state,
IMEI, ICCID, Model, Manufacturer, Serial, Revision, IMSI, SIM State, PIN
state, GSM signal, WCDMA RSCP, WCDMA EC/IO, LTE RSRP, LTE SINR, LTE RSRQ,
CELL ID, Operator, Operator number, Connection type |
SYSTEM CHARACTERISTICS
|
|
|
CPU |
Quad-core
ARM Cortex A7, 717 MHz |
|
RAM |
256
MB, DDR3 |
|
FLASH storage |
256
MB, SPI Flash |
FIRMWARE / CONFIGURATION
|
|
|
WEB UI |
Update
FW from file, check FW on server, configuration profiles, configuration
backup |
|
FOTA |
Update
FW |
|
RMS |
Update
FW/configuration for multiple devices at once |
|
Keep settings |
Update
FW without losing current configuration |
FIRMWARE CUSTOMISATION
|
|
|
Operating
system |
RutOS
(OpenWrt based Linux OS) |
|
Supported
languages |
Busybox
shell, Lua, C, C++, and Python, Java in Package manager |
|
Development
tools |
SDK
package with build environment provided |
|
GPL
customization |
You
can create your own custom, branded firmware and web page application by
changing colours, logos, and other elements in our firmware to fit your or
your clients’ needs. |
LOCATION TRACKING
|
|
|
GNSS |
GPS,
GLONASS, BeiDou, Galileo and QZSS |
|
Coordinates |
GNSS
coordinates via WebUI, SMS, TAVL, RMS |
|
NMEA |
NMEA
0183 |
|
NTRIP |
NTRIP
protocol (Networked Transport of RTCM via Internet Protocol) |
|
Server
software |
Supported
server software TAVL, RMS |
|
Geofencing |
Configurable
multiple geofence zones |
USB
|
|
|
Data rate |
USB
2.0 |
|
Applications |
Samba
share, USB-to-serial |
|
External
devices |
Possibility
to connect external HDD, flash drive, additional modem, printer, USB-serial
adapter |
|
Storage
formats |
FAT,
FAT32, exFAT, NTFS (read-only), ext2, ext3, ext4 |
INPUT / OUTPUT
|
|
|
Input |
1
x Digital Input, 0 - 6 V detected as logic low, 8 - 30 V detected as logic
high |
|
Output |
1
x Digital Output, Open collector output, max output 30 V, 300 mA |
|
Events |
Email,
RMS, SMS |
|
I/O juggler |
Allows
to set certain I/O conditions to initiate event |
POWER
|
|
|
Connector |
4-pin
industrial DC power socket |
|
Input voltage
range |
9
- 50 VDC, reverse polarity protection, voltage surge/transient protection |
|
PoE (passive) |
Possibility
to power up through LAN1 port, not compatible with IEEE802.3af, 802.3at and
802.3bt standards, Mode B, 9 - 30 VDC |
|
Power
consumption |
Idle:
< 4 W, Max: < 22 W |
PHYSICAL INTERFACES
|
|
|
Ethernet |
5
x RJ45 ports, 10/100/1000 Mbps |
|
I/O’s |
1
x Digital Input, 1 x Digital Output on 4-pin power connector |
|
Status LEDs |
4
x connection status LEDs, 6 x connection strength LEDs, 10 x Ethernet port
status LEDs, 4 x WAN status LEDs, 1 x Power LED, 2 x 2.4G and 5G Wi-Fi LEDs |
|
SIM |
2
x SIM slots (Mini SIM - 2FF), 1.8 V/3 V, external SIM holders |
|
Power |
1
x 4-pin power connector |
|
Antennas |
4
x SMA for LTE, 2 x RP-SMA for WiFi, 1 x RP-SMA for Bluetooth, 1 x SMA for
GNNS |
|
USB |
1
x USB A port for external devices |
|
Reset |
Reboot/User
default reset/Factory reset button |
|
Other |
1
x Grounding screw |
PHYSICAL SPECIFICATION
|
|
|
Casing
material |
Full
aluminium housing |
|
Dimensions (W
x H x D) |
132
x 44.2 x 95.1 mm |
|
Weight |
540
g |
|
Mounting
options |
DIN
rail (can be mounted on two sides), flat surface placement |
OPERATING ENVIRONMENT
|
|
|
Operating
temperature |
-40
°C to 75 °C |
|
Operating
humidity |
10%
to 90% non-condensing |
|
Ingress
Protection Rating |
IP30
|
