WIRELESS
|
|
|
Wireless mode |
802.11b/g/n/ac
Wave 2 (Wi-Fi 5) with data transmission rates up to 867 Mbps (Dual Band,
MU-MIMO) |
|
Wi-Fi security |
WPA2-EAP/WPA3-EAP
Mixed Mode, WPA3-EAP, WPA2-PSK/WPA3-SAE Mixed Mode, WPA3-SAE, OWE,
WPA-PSK/WPA2-PSK Mixed Mode, WPA2-PSK, WPA2-EAP; AES-CCMP, TKIP, Auto Cipher
modes, isolate clients |
|
SSID/ESSID |
ESSID
stealth mode (Hide SSID) |
|
Wi-Fi users |
Up
to 100 simultaneous connections |
|
Wireless mesh/roaming |
Fast
roaming (802.11r), BSS transition management (802.11v), radio resource
measurement (802.11k) |
|
Wireless MAC filter |
Whitelist,
blacklist |
|
Wireless QR code generator |
Once
scanned, a user will automatically enter your network without needing to
input login information. |
ETHERNET
|
|
|
Ethernet |
1
x RJ45 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az
standards, supports auto MDI/MDIX crossover |
|
NETWORK
|
|
|
Network protocols |
TCP,
UDP, IPv4, IPv6, ICMP, HTTP, HTTPS, SSL/TLS, ARP, SSH, DHCP client, SNMP |
|
SECURITY
|
SSH
key based, HTTPS, CLI, IP & Login attempts block |
|
Authentication |
Tag-based
VLAN separation |
|
VLAN |
|
|
API
|
|
|
Teltonika Networks Web API
(beta) support |
Expand
your device's possibilities by using a set of configurable API endpoints to
retrieve or change data. For more information, please refer to this
documentation: https://developers.teltonika-networks.com |
MONITORING & MANAGEMENT
|
|
|
WEB UI |
HTTP/HTTPS,
status, configuration, FW update, CLI, troubleshoot, event log, system log,
kernel log |
|
FOTA |
Firmware
update from server, automatic notification |
|
SSH |
SSH
(v1, v2) |
|
Email |
Receive
email message status alerts of various services |
|
JSON-RPC |
Management
API over HTTP/HTTPS |
|
RMS |
Teltonika
Remote Management System (RMS) |
SYSTEM CHARACTERISTICS
|
|
|
CPU |
MediaTek,
Dual-Core, 880 MHz, MIPS 1004Kc |
|
RAM |
256
MB, DDR3 |
|
FLASH storage |
16MB,
SPI NOR Flash |
FIRMWARE / CONFIGURATION
|
|
|
WEB UI |
Update
FW from file, check FW on server, configuration profiles, configuration
backup |
|
FOTA |
Update
FW |
|
RMS |
Update
FW/configuration for multiple devices at once |
|
Keep settings |
Update
FW without losing current configuration |
FIRMWARE CUSTOMISATION
|
|
|
Operating system |
RutOS
(OpenWrt based Linux OS) |
|
Supported languages |
Busybox
shell, Lua, C, C++ |
|
Development tools |
SDK
package with build environment provided |
|
GPL customization |
You
can create your own custom, branded firmware and web page application by
changing colours, logos, and other elements in our firmware to fit your or
your clients’ needs. |
POWER
|
|
|
Connector |
RJ45
Socket |
|
Input voltage range |
44.0
– 57.0 V |
|
PoE standards |
802.3af
PoE Class 1
|
PHYSICAL INTERFACES
|
|
|
Ethernet |
1
x RJ45 port, 10/100/1000 Mbps |
|
Status LEDs |
1
x Power LED (can be turned off from web-UI) |
|
Antennas |
2
x Internal for 2.4 GHz Wi-Fi, 2 x Internal for 5 GHz Wi-Fi |
|
Antennas specifications |
2
x 2400 - 2500 MHz, 50 Ω, VSWR <2.7, gain < 4.9 dBi, omnidirectional |
|
Antennas specifications |
2 x 5150 - 5850 MHz, 50 Ω, VSWR <2, gain < 5.02 dBi,
omnidirectional |
|
Reset |
Reboot/User
default reset/Factory reset button |
PHYSICAL SPECIFICATION
|
|
|
Casing material |
UV
stabilized plastic |
|
Dimensions |
Ø
158 mm x 30 mm |
|
Weight |
190
g |
|
Mounting options |
AP
Mounting Bracket (for ceiling mount) |
|
OPERATING ENVIRONMENT
|
|
|
Operating temperature |
-40
°C to 75 °C |
|
Operating humidity |
10%
to 90% non-condensing |
|
Ingress Protection Rating |
IP30 |
|
REGULATORY & TYPE APPROVALS
|
|
|
Regulatory |
CE,
UKCA, FCC, IC, RCM, CB, EAC, UCRF, WEEE |
EMC EMISSIONS & IMMUNITY
|
|
|
Standards |
EN
55032:2015+A11:2020 |
|
Standards |
EN 55035:2017+A11:2020 |
| Standards |
EN 61000-3-3:2013+A1:2019+A2:2021 |
| Standards |
EN IEC 61000-3-2:2019+A1:2021 |
| Standards |
EN 301 489-1 V2.2.3 |
| Standards |
EN 301 489-17 V3.2.4 |
|
ESD |
EN
61000-4-2:2009 |
|
Radiated Immunity |
EN
IEC 61000-4-3:2020 |
|
EFT |
EN
61000-4-4:2012 |
|
Surge Immunity (AC Mains
Power Port) |
EN
61000-4-5:2014 + A1:2017 |
|
CS |
EN
61000-4-6:2014 |
|
DIP |
EN
IEC 61000-4-11:2020 |
RF
|
|
|
Standards |
EN
300 328 V2.2.2; EN 300 893 V2.1.1; EN 300 440 V2.2.1 |
SAFETY
|
|
|
Standards |
IEC
62368-1:2018 |
|
Standards |
EN IEC 62368-1:2020+A11:2020 |
| Standards |
EN IEC 62311:2020
|
| Standards |
|
